MSI MPG 346CQRF X24 34INCH UWQHD 240HZ MONITOR

MODEL NO: MSI MPG 346CQRF X24 UWQHD 240HZ MONITOR

Specifications:

Panel Size 34"

Active Display Area (mm) 797.22 (H) x 333.72 (V)

Curvature Curve 1500R

Panel Type Rapid VA

Panel Resolution 3440 x 1440 (UWQHD)

Pixel Pitch (H x V) 0.23175 (H) x 0.23175 (V)

Aspect Ratio 21:9

Brightness (nits) SDR: 400 cd/m²

HDR: 400 cd/m² (Peak)

Contrast Ratio 4000:1

DCR 100000000:1

Signal Frequency 71.52~357.6KHz (H) / 48~240Hz (V)

ACTIVATED RANGE 48~240Hz

Refresh Rate 240Hz

Response time 0.5ms (GtG, Min.)

DYNAMIC REFRESH RATE

TECHNOLOGY Adaptive-Sync

HDR Support VESA DisplayHDR 400

Video ports

2x HDMI™ 2.1 (UWQHD@240Hz)

1x DisplayPort 1.4a (HBR3)

1x Type-C (DP alt.) w/ 98W Power

Delivery

USB ports 2x USB 2.0 Type-A

1x USB 2.0 Type-B

Audio ports 1 x Headphone-out

Viewing Angle 178° (H) / 178° (V)

Adobe RGB / DCI-P3 / sRGB 85% / 85% / 110% (CIE1976 Standard)

Surface Treatment Anti-glare

Display Colors 1.07B, 10 bits (8 bits + FRC)

Console Mode

Supported Resolution &!important; Refresh Rate:

1080p: 60Hz and 120Hz

1440p: 60Hz and 120Hz

HDMI™ CEC: Supported

VRR: PS5 and Xbox Supported

Frameless Design Yes

PIP / PBP Function Yes

Power Type Internal Power Board

Power Input 100~240V, 50/60Hz

Adjustment (Tilt) -5° ~ 15°

Adjustment (Swivel) -30° ~ 30°

Adjustment (Height) 0 ~ 110 mm

Kensington Lock Yes

VESA Mounting 100 x 100 mm

Dimension with Stand (W x D x

H)

808 x 278.3 x 537.9 mm

(31.8 x 10.9 x 21.1 inch)

Dimension without Stand (W x

D x H)

808 x 111.9 x 363.9 mm

(31.8 x 4.4 x 14.3 inch)

Weight (NW / GW) 7.9 kg (17.4 lbs) / 12 kg (26.4 lbs)

Carton Dimension (W X D X H) 995 x 170 x 492 mm

(39.1 x 6.6 x 19.3 inch)

Accessories

1x HDMI™ Cable (2.1), 1x DisplayPort

Cable (1.4a), 1x Power Cord (C13), 1x

Quick Guide, 1x USB Type-C Cable, 1x

USB Type-B to A Cable, 4x Stand Screw

Note

HDMI: 3440 x 1440 (Up to 240Hz)

DisplayPort: 3440 x 1440 (Up to 240Hz)

Type-C: 3440 x 1440 (Up to 240Hz)

Support: HDMI™ CEC, KVM, PIP/PBP
