MERCUSYS MW300D 300MBPS WIRELESS N ADSL2+ MODEM ROUTER

MODEL NO: MERCUSYS MW300D | 300MBPS WIRELESS N ADSL2+ MODEM ROUTER

Specifications:

Wireless Standards

IEEE 802.11b/g/n

Frequency

2.4 - 2.4835GHz

WiFi Speeds

• 11n: Up to 300Mbps (Dynamic)

• 11g: Up to 54Mbps (Dynamic)

• 11b: Up to 11Mbps (Dynamic)

Reception Sensitivity

• 270M: -73dBm@10% PER • 11M: -90dBm@10% PER

• 130M: -75dBm@10% PER • 6 M: -94dBm@10% PER

• 54M: -77dBm@10% PER • 1 M: -96dBm@10% PER

Transmission Power

<!important; 20dBm (EIRP)

Wireless Security

WPA-PSK / WPA2-PSK

Wireless Functions

Enable/Disable Wireless Radio

Hardware

Dimensions

114 x 94 x 26 mm

Button

WPS/Reset Button

External Power Supply

9V/0.6A

Antenna Type

2× External Antennas

Ethernet Ports

3*10/100Mbps LAN Ports

1*RJ11 Port

Software

DHCP

Server

Others

Package Contents

• 300Mbps Wireless N ADSL2+

Modem Router (MW300D)

• Power Adapter

• Quick Installation Guide

• 2× RJ11 Phone Cable

• RJ45 Ethernet Cable

• External DSL Splitter

Environment

• Operating Temperature: 0°C~40°C (32°F~104°F)

• Storage Temperature: -40°C~70°C (-40°F~158°F)

• Operating Humidity: 10%~90% Non-Condensing

• Storage Humidity: 5%~90% Non-Condensing
