TP-LINK RE200 AC750 MESH WI-FI RANGE EXTENDER 5GHz

MODEL NO: TP-LINK RE200 AC750 MESH WI-FI RANGE EXTENDER 5GHz

Specifications:

SPEED

Package Contents 433Mbps Universal Wi-Fi Range Extender RE200 AC750

WIRELESS

Working Modes Range Extender/Access Point

HARDWARE FEATURES

Standards and Protocols IEEE802.11ac,IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Plug Type EU, UK, US, AU

Interface 1 x 10/100Mbps Ethernet Port (RJ45)

Button RE (Range Extender) Button, Reset Button

Input Power 100-240V~50/60Hz

Max. Power Consumption About 6.5W

Dimensions ( W x D x H ) 4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm)

Antenna 3 x internal

WIRELESS FEATURES

Wireless Standards IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz

Frequency 2.4GHz &!important; 5GHz

Signal Rate 5GHz:Up to 433Mbps

2.4GHz:Up to 300Mpbs

Working Modes Range Extender/Access Point

Reception Sensitivity 2.4G:

270M: -70dBm@10% PER

130M: -70dBm@10% PER

108M: -73dBm@10% PER

54M: -75dBm@10% PER

11M: -86dBm@8% PER

6M: -92dBm@10% PER

1M: -94dBm@8% PER

5G:

390M: -60dBm@10% PER

29.3M: -83dBm@10% PER

180M: -64dBm@10% PER

13.5M: -87dBm@10% PER

78M: -68dBm@10% PER

6.5M: -90dBm@10% PER

54M: -75dBm@10% PER

6M：-90dBm@10% PER

Wireless Modes Range Extender/Access Point

Wireless Functions WMM (Wi-Fi Multimedia)

Wireless Statistic

Domain Login Function

Wireless Security 64/128/152-bit WEP

WPA-PSK / WPA2-PSK

Transmission Power <!important; 20 dBm (EIRP)

Mesh Technology EasyMesh

OTHERS

Certification CE, FCC, RoHS

Package Content AC750 Wi-Fi Range Extender RE200

Quick Installation Guide

System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.

Environment Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
