GAMDIAS HELIOS M1 650B 80 PLUS BRONZE POWER SUPPLY

MODEL NO: GAMDIAS HELIOS M1 650B 80 PLUS BRONZE POWER SUPPLY

Specifications:

Type

ATX12V v2.4

Efficiency

Meet 80 PLUS Bronze efficiency

Power Factor Correction

APFC with PF value of 0.99

Support MB Sync

No

Dimension (L x W x H)

140 x 150 x 86 mm

Support C6/C7 power state

Yes

AC Input

100-240V / 5-10A / 47-63Hz

DC Output

+3.3V / +5V / +12V / -12V / +5Vsb

Max. Output Current

18A / 18A / 48A / 0.4A / 2.5A

Max. Output Power

100W / 576W / 4.8W / 12.5W

Total Power

650W

Protection

OVP / UVP / OPP / OCP / SCP

Main Power

1 (20+4 Pin)

CPU

1 (4+4 Pin)

PCI-E

2 (6+2 Pin)

SATA

5 (5 Pin)

Molex

3 (4 Pin)

Modular

Non Modular

Flat Cable

Yes

Cooling System

120mm hydraulic bearing fan

Silent Mode

No
